19" 3U Wall Brackets, Depth-Adjustable
Priser kun synlige for indloggede brugere
19" 3U Wall Bracket, Depth-Adj., RAL7035
Varenummer:
691831GR.3
EAN nr.:
4049759209193
Produktinformation für 19" 3U Wall Bracket, Depth-Adj., RAL7035
19" wall brachet with adjustable mounting depth (225 .. 345 mm)
Material steel
Paint finish RAL7035, light grey / RAL9005, jet black / RAL9010, pure white
Material steel
Paint finish RAL7035, light grey / RAL9005, jet black / RAL9010, pure white
Tekniske egenskaber
| Degree of protection: | IP00 |
|---|---|
| Demountable: | True |
| Material: | steel |
| Model: | Other |
| Modular spacing: | 482.6 mm (19 inch) |
| Mounting level: | Front side |
| Number of cartons: | 1 |
| Number of doors: | 0 |
| Surface finishing: | powder coating |
| Type of profile rail: | L-shaped |
| Type of ventilation: | Passive |
| With earthing: | True |
| With front door: | True |
| With roof plate: | True |
| With sidewall: | True |
Varianter
| Art. Nej. | Betegnelse | Max. Load | Width | Max. load capacity | Depth | Number of height units | Colour | Height | RAL-number | |
|---|---|---|---|---|---|---|---|---|---|---|
| 691831GR.3 | 19" 3U Wall Bracket, Depth-Adj., RAL7035 | 10 kg | 528 mm | 10 kg | 345 mm | 3 U | grey | 134 mm | 7035 | |
| 691831TS.3 | 19" 3U Wall Bracket, Depth-Adj., RAL9005 | 10 kg | 528 mm | 10 kg | 345 mm | 3 U | black | 134 mm | 9005 | |
| 691831WS.3 | 19" 3U Wall Bracket, Depth-Adj., RAL9010 | 10 kg | 528 mm | 10 kg | 345 mm | 3 U | white | 134 mm | 9010 |
