RJ45 Patch cable S/FTP, Cat.6A, VC LED, black

Priser kun synlige for indloggede brugere

RJ45 Patch cable S/FTP, Cat.6A, VC LED, 1m, black
Varenummer: DCK1001SW.1
EAN nr.: 4049759086718
Stück

Produktinformation für RJ45 Patch cable S/FTP, Cat.6A, VC LED, 1m, black

The shielded Cat.6A RJ45 patch cable provides excellent performance for 10 Gigabit Ethernet applications. With the help of a detector (Art.-Nr. DC10001 oder DC10001USB) light emitting diodes are excited in both RJ45 plugs of the patch cable. The illuminated RJ45 plugs make it easy to track the cable path.

Cross section 4 x 2 x AWG26/7
Length imprint on the grommet

Tekniske egenskaber

(Halogenfree): True
AWG-size: 26/7
Allocation: acc. TIA/EIA 568B
Anti-kink sleeve: put-on
Area of Application: Data center, Industrial Ethernet, Structured cabling
Bandwidth: 500MHz
Bending radius: >20 mm
Cable construction: 4x2
Cable type: S/FTP
Category: 6A (TIA)
Colour anti-kink sleeve: black
Colour outer sheath: black
Conductive shield: 360° shield contact
Conductor Material: Copper
Conductor resistance DC: 165 Ω/km
Connector: IEC 60603-7-51
Connector type: RJ45 LED
Current capacity: max. 1 A
Fire retardant version: True
Flame-retardant: acc. IEC60332-3
Halogen-free: yes
Impedance: 100 ±15 Ω
Insulation resistance: > 5000 MΩ
Jacket material: LSZH
Length imprint: True
Locking lever: True
Loop resistance: 330 Ω/km
Low smoke: acc. IEC61034
Model: Shielded
NVP value: - %
Oil resistant (acc. EN 60811-2-1): False
Oil resistant (according to EN 60811-404): False
Operating-/ tempering voltage: max. 50 V DC
Outer diameter of the cable: 6.2 mm
POE class: 4PPoE acc. to IEEE802.3bt, PoE+ acc. to IEEE802.3at, PoE acc. to IEEE802.3af
Pin assignment: 1:1
Suitable for degree of protection (IP): IP20
Temperature Range (Installation): 0 – 50 °C
Temperature Range (Operation): -25 – 60 °C
Total screening: >65 %
Transmission: 10Gbit
Type of connector connection 1: RJ45 8(8)
Type of connector connection 2: RJ45 8(8)

Varianter

Art. Nej. Betegnelse Length Length tolerance
DCK1001SW.1 RJ45 Patch cable S/FTP, Cat.6A, VC LED, 1m, black 1.0 m ±5 % Vælg varianter
DCK1001SW.2 RJ45 Patch cable S/FTP, Cat.6A, VC LED, 2m, black 2.0 m ±5 % Vælg varianter
DCK1001SW.3 RJ45 Patch cable S/FTP, Cat.6A, VC LED, 3m, black 3.0 m ±5 % Vælg varianter
DCK1001SW.5 RJ45 Patch cable S/FTP, Cat.6A, VC LED, 5m, black 5.0 m ±5 % Vælg varianter
DCK1001SW.10 RJ45 Patch cable S/FTP, Cat.6A, VC LED, 10m, black 10.0 m ±5 % Vælg varianter
DCK1001SW.15 RJ45 Patch cable S/FTP, Cat.6A, VC LED, 15m, black 15.0 m ±5 % Vælg varianter
