Outdoor Cable A-DQ(ZN)B2Y SM G652.D 2000N
Priser kun synlige for indloggede brugere
A-DQ(ZN)B2Y 4x12E 9/125µ G652D, PE, black
Varenummer:
55448.1A
EAN nr.:
3700223691432
Produktinformation für A-DQ(ZN)B2Y 4x12E 9/125µ G652D, PE, black
Areas of application:
Outdoor cable (suitable for outdoor installation)
For connecting buildings
To the campus cabling
For direct burial (according to installation instructions)
For insertion in plastic pipe systems (not for blow in)
For installation in cable ducts and on platforms
Characteristics:
Easy to process construction
Tearing thread for opening/removing the cable sheath
Gel-free cable construction for clean and quick installation
Small dimensions
High installation stability
The cable diameter can vary
Outdoor cable (suitable for outdoor installation)
For connecting buildings
To the campus cabling
For direct burial (according to installation instructions)
For insertion in plastic pipe systems (not for blow in)
For installation in cable ducts and on platforms
Characteristics:
Easy to process construction
Tearing thread for opening/removing the cable sheath
Gel-free cable construction for clean and quick installation
Small dimensions
High installation stability
The cable diameter can vary
Tekniske egenskaber
| Application: | Outside |
|---|---|
| Armouring: | True |
| Blow in: | False |
| Cable & Fiber: |
IEC/EN 60793 IEC/EN 60794-1 |
| Cable metal free: | True |
| Cable silicone free: | True |
| Cabling standards: |
EN 50173-1 ISO/IEC 11801 |
| Colour outer sheath: | black |
| Crush resistance: | 150 N/cm |
| Fiber Colours: |
black blue brown green grey orange red rose turquoise violet white yellow |
| Fiber marking: | Colour |
| Fiber type: | Single mode 9/125 |
| Fibre category: | G652.D |
| Jacket material: | PE |
| Longitudinal water blocking: | True |
| Radial water blocking: | True |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -25 – 60 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Transmission standards: | IEEE 802.3 10Mbit to 100Gbit |
| Tube marking: | Colour |
| Tube Ø: | 2.8 mm |
| Type of tube: | Central tube |
| With rodent protection: | True |
| With strain relief: | True |
