Adapter SC/APC Duplex SM one piece, with internal Shutter
Adapter SC/APC Duplex OS2 green with shutter
Varenummer:
53316.36
EAN Nr.:
4049759224851
Produktinformation til Adapter SC/APC Duplex OS2 green with shutter
LC Duplex adapters in coloured plastic housing. Suitable for SC-Duplex cut-outs. The couplings are equipped with an internal laser shutter. Fastening options via clips, also via sheet metal or threaded screws these are available as accessories.
Tekniske egenskaber
| Accessories: | Self-Tapping Screw |
|---|---|
| Conform to Standard: | IEC61754-4 |
| Construction type: | SC Duplex |
| Dust cover: | true |
| Height: | 9.3 mm |
| Internal Shutter: | True |
| Length: | 27.1 mm |
| Material housing: | Plastic |
| Material sleeve: | Ceramics |
| Operating temperature: | -25 – 70 °C |
| Storage Temperature: | -40 – 80 °C |
| Type of connector connection 1: | SC duplex |
| Type of connector connection 2: | SC duplex |
| Type of fastening: | Screw/snap in |
| Type of housing: | With flange |
| Width: | 34.6 mm |
