FTTH Indoor Drop Cable 2,65mm LSZH
Priser kun synlige for indloggede brugere
FTTH Indoor Drop Cable 2,65mm LSOH, 4 fiber G.657.A2, CPR Dca
Varenummer:
FTTH-DROP-4
EAN nr.:
4049759212261
Produktinformation für FTTH Indoor Drop Cable 2,65mm LSOH, 4 fiber G.657.A2, CPR Dca
Laying indoors
The cable is compatible with an installation in service shaft, and visible mounting by bonding or stapling.
The cable is compatible with an installation in service shaft, and visible mounting by bonding or stapling.
Tekniske egenskaber
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable & Fiber: |
IEC/EN 60793 IEC/EN 60794-1 IEC 60794-3 |
| Cable metal free: | True |
| Cabling standards: |
EN 50173-1 ISO/IEC 11801 |
| Circuit integrity: | False |
| Colour outer sheath: | ivory |
| Euro Class: | Dca |
| Fiber Colours: |
blue green red yellow |
| Fiber marking: | Colour |
| Fiber type: | Single mode |
| Fibre category: | G657.A2 |
| Flame-retardant: | According to EN 60332-1-2 |
| Halogen free (according to EN 60754-1/2): | True |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 1310nm: | 0.36 |
| IL max. (dB/km) 1550nm: | 0.23 |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Oil resistant (acc. EN 60811-2-1): | False |
| Oil resistant (according to EN 60811-404): | False |
| Radial water blocking: | False |
| Rayleigh Backscatter Coefficient 1310nm: | 1.467 |
| Rayleigh Backscatter Coefficient 1550nm: | 1.468 |
| Rayleigh Backscatter Coefficient 1625nm: | 1.468 |
| Resistant to chemicals: | False |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -5 – 60 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Type of tube: | Semi-tight fibre |
| UV resistance: | False |
| With rodent protection: | False |
| With strain relief: | True |
