FTTH Indoor Drop Cable 3mm LSZH
FTTH Indoor Drop Cable 3mm LSOH, 2 fiber G.657.A2, CPR Dca
Varenummer:
FTTH-DROP-2
EAN nr.:
4049759212254
Produktinformation til FTTH Indoor Drop Cable 3mm LSOH, 2 fiber G.657.A2, CPR Dca
Laying indoors
The cable is compatible with an installation in service shaft, and visible mounting by bonding or stapling.
The cable is compatible with an installation in service shaft, and visible mounting by bonding or stapling.
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable & Fiber: | IEC/EN 60793, IEC/EN 60794-1, IEC 60794-3 |
| Cable metal free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | ivory |
| Fiber Colours: | green, red |
| Fiber marking: | Colour |
| Fibre category: | OS2 G657A2 |
| Fibre type: | Single mode 9/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 1310nm: | 0.36 |
| IL max. (dB/km) 1550nm: | 0.23 |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Oil resistant (acc. EN 60811-2-1): | False |
| Oil resistant (according to EN 60811-404): | False |
| Radial water blocking: | False |
| Rayleigh Backscatter Coefficient 1310nm: | 1.467 |
| Rayleigh Backscatter Coefficient 1550nm: | 1.468 |
| Rayleigh Backscatter Coefficient 1625nm: | 1.468 |
| Resistant to chemicals: | False |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -5 – 70 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Type of tube: | Semi-tight fibre |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
Tekniske egenskaber
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable & Fiber: | IEC/EN 60793, IEC/EN 60794-1, IEC 60794-3 |
| Cable metal free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | ivory |
| Fiber Colours: | green, red |
| Fiber marking: | Colour |
| Fibre category: | OS2 G657A2 |
| Fibre type: | Single mode 9/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 1310nm: | 0.36 |
| IL max. (dB/km) 1550nm: | 0.23 |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Oil resistant (acc. EN 60811-2-1): | False |
| Oil resistant (according to EN 60811-404): | False |
| Radial water blocking: | False |
| Rayleigh Backscatter Coefficient 1310nm: | 1.467 |
| Rayleigh Backscatter Coefficient 1550nm: | 1.468 |
| Rayleigh Backscatter Coefficient 1625nm: | 1.468 |
| Resistant to chemicals: | False |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -5 – 70 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Type of tube: | Semi-tight fibre |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
Produktinformation til FTTH Indoor Drop Cable 3mm LSOH, 2 fiber G.657.A2, CPR Dca
Laying indoors
The cable is compatible with an installation in service shaft, and visible mounting by bonding or stapling.
The cable is compatible with an installation in service shaft, and visible mounting by bonding or stapling.
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable & Fiber: | IEC/EN 60793, IEC/EN 60794-1, IEC 60794-3 |
| Cable metal free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | ivory |
| Fiber Colours: | green, red |
| Fiber marking: | Colour |
| Fibre category: | OS2 G657A2 |
| Fibre type: | Single mode 9/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 1310nm: | 0.36 |
| IL max. (dB/km) 1550nm: | 0.23 |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Oil resistant (acc. EN 60811-2-1): | False |
| Oil resistant (according to EN 60811-404): | False |
| Radial water blocking: | False |
| Rayleigh Backscatter Coefficient 1310nm: | 1.467 |
| Rayleigh Backscatter Coefficient 1550nm: | 1.468 |
| Rayleigh Backscatter Coefficient 1625nm: | 1.468 |
| Resistant to chemicals: | False |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -5 – 70 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Type of tube: | Semi-tight fibre |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable & Fiber: | IEC/EN 60793, IEC/EN 60794-1, IEC 60794-3 |
| Cable metal free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | ivory |
| Fiber Colours: | green, red |
| Fiber marking: | Colour |
| Fibre category: | OS2 G657A2 |
| Fibre type: | Single mode 9/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 1310nm: | 0.36 |
| IL max. (dB/km) 1550nm: | 0.23 |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Oil resistant (acc. EN 60811-2-1): | False |
| Oil resistant (according to EN 60811-404): | False |
| Radial water blocking: | False |
| Rayleigh Backscatter Coefficient 1310nm: | 1.467 |
| Rayleigh Backscatter Coefficient 1550nm: | 1.468 |
| Rayleigh Backscatter Coefficient 1625nm: | 1.468 |
| Resistant to chemicals: | False |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -5 – 70 °C |
| Temperature Range (Storage): | -40 – 70 °C |
| Type of tube: | Semi-tight fibre |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
Producentangivelse
EFB-Elektronik GmbH
Striegauer Straße 1
33719 Bielefeld
info@efb-elektronik.de
https://www.efb-elektronik.de/kontakt
