INFRALAN® I-B(ZN)BH 9/125µ, OS2
INFRALAN® I-B(ZN)BH OS2 24E (2x12) B2ca 3000N LSZH yellow 8.3mm G657A1
Varenummer:
56324.2OS2-CPR
EAN Nr.:
4049759223182
Produktinformation til INFRALAN® I-B(ZN)BH OS2 24E (2x12) B2ca 3000N LSZH yellow 8.3mm G657A1
Fields of application:
For building connections
For campus cabling
For use in plastic pipe systems
For installation in cable ducts and on flatbeds
Characteristics:
Easy to use construction
Gel-free cable construction for clean and fast assembly
Small dimensions
High laying stability
Fire behaviour tested and certified according to
Construction Products Regulation (see Euro fire class)
Cable diameter may vary
For building connections
For campus cabling
For use in plastic pipe systems
For installation in cable ducts and on flatbeds
Characteristics:
Easy to use construction
Gel-free cable construction for clean and fast assembly
Small dimensions
High laying stability
Fire behaviour tested and certified according to
Construction Products Regulation (see Euro fire class)
Cable diameter may vary
Tekniske egenskaber
| Application: | Inside |
|---|---|
| Armouring: | True |
| Blow in: | False |
| Cable metal free: | True |
| Cable silicone free: | True |
| Colour outer sheath: | yellow |
| Crush resistance: | 1000 N/dm |
| Fiber marking: | Colour |
| Fibre category: | OS2 G657A1 |
| Fibre type: | Singlemode 9/125 |
| Flame retardant: | According to EN 60332-1-2 |
| Harmonised Standard: | EN 50575 |
| Jacket material: | LSZH |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -10 – 70 °C |
| Temperature Range (Storage): | -25 – 70 °C |
| Tube marking: | Colour |
| Type of tube: | Stranded loose tube |
| With rodent protection: | True |
| With strain relief: | True |
Varianten
| Art. Nr. | Bezeichnung | Category | Cable Ø | Tensile force max. | CPR-Class | Number of fibers | Construct | Outer diameter approx. | Bending radius | VDE-Name | Weight | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 56324.2OS2-CPR | INFRALAN® I-B(ZN)BH OS2 24E (2x12) B2ca 3000N LSZH yellow 8.3mm G657A1 | OS2 | 8.3 mm | 3000 N | B2ca | 24 | (2x12) | 8.3 mm | 166 mm | I-B(ZN)BH 24E 9/125µ | 75 kg/km | |
| 56348.2OS2-CPR | INFRALAN® I-B(ZN)BH OS2 48E (4x12) B2ca 3000N LSZH yellow 8.3mm G657A1 | OS2 | 8.3 mm | 3000 N | B2ca | 48 | (4x12) | 8.3 mm | 166 mm | I-B(ZN)BH 48E 9/125µ | 75 kg/km |
Producentangivelse
EFB-Elektronik GmbH
Striegauer Str. 1
33719 Bielefeld
info@efb-elektronik.de
https://www.efb-elektronik.de
