IP68 Cable gland for RJ45 field assembly plugs, 6.5-9.0mm
IP68 Cable gland for RJ45 field assembly plugs, sealing for 6.5-9.0mm OD
Varenummer:
IP68FST6AB
EAN Nr.:
4049759186746
Produktinformationen für IP68 Cable gland for RJ45 field assembly plugs, sealing for 6.5-9.0mm OD
IP68 cable gland for RJ45 field-assembly plugs
With bayonet lock to IEC61076-3-106
Straight outlet 180 °
Delivery unequipped
Scope of delivery: 3-part consisting of:
1x IP68 cable gland housing (without plug)
1x Cable seal IP68FST6AA: 6,5 - 9,0 mm
1x Strain relief fitting
Accessories:
IP68 Cap: IP68STCAP
Field assembly plug: 88035.1, 88035P8.1, 88035UTP.1, 88035AV.1, IVB-6A-S
With bayonet lock to IEC61076-3-106
Straight outlet 180 °
Delivery unequipped
Scope of delivery: 3-part consisting of:
1x IP68 cable gland housing (without plug)
1x Cable seal IP68FST6AA: 6,5 - 9,0 mm
1x Strain relief fitting
Accessories:
IP68 Cap: IP68STCAP
Field assembly plug: 88035.1, 88035P8.1, 88035UTP.1, 88035AV.1, IVB-6A-S
Technische Eigenschaften
Assembly arrangement: | base element with complete housing |
---|---|
Material: | Plastic |
Material quality: | Duroplast |
Suitable for degree of protection (IP): | IP68 |
Temperature: | -40 / +85 Celsius |
Type of fastening: | screw mounting |
Type of locking: | Bayonet lock |
With dust cover: | True |
With strain relief: | True |
