Flat Cables, pitch 1.00
Ribbon Cable, pitch 1.00 AWG28/7, 44-pole
Varenummer:
92944.30R
EAN Nr.:
4049759052256
Produktinformationen für Ribbon Cable, pitch 1.00 AWG28/7, 44-pole
AWG28/7
Grey with identifier core (red)
30.5 m rolls
Individual wires, tin-plated
Grey with identifier core (red)
30.5 m rolls
Individual wires, tin-plated
Technische Eigenschaften
| AWG-size: | 28 |
|---|---|
| Conductor category: | Kl.1 = single wire |
| Core insulation: | PVC |
| Diameter conductor: | 0.127 mm |
| Flame-retardant: | False |
| Halogen free (acc. EN 50267-2-2): | False |
| Low smoke (acc. EN 61034-2): | False |
| Low temperature resistant (acc. EN 60811-1-4): | False |
| Nominal cross section conductor: | 0.09 mm² |
| Nominal voltage U: | 300 V |
| Nominal voltage U0: | - V |
| Oil resistant (acc. EN 60811-2-1): | False |
| Operating temperature, fix: | -30..+105 – °C |
| Operating temperature, flexible: | -20..+105 – °C |
| Screen: | False |
