RJ45 Keystone STP, Cat.6A, 500MHz, Slimline
Priser kun synlige for indloggede brugere
RJ45 Keystone Slimline, Cat.6A, silver
Varenummer:
E-20095
EAN nr.:
4049759155056
Produktinformation für RJ45 Keystone Slimline, Cat.6A, silver
The RJ45 keystone module slimline garantues very good characteristics for 10Gbit Ethernet application. Special tools are not needed. The assembling is carried out fast and easy. With the RJ45 module slimline you get a full shielded module which provides you good longterm service in your network infrastructure.
Specifications:
Extremely small design „Slimline“ for installation with UAE frame sets, design capable
Compact cable presorter for contacting IDC-Terminals AWG 24/1 .. 22/1
Pair management according to TIA 568A /B colour codes
Appropriate for all distribution panels and frames with keystone slots
Flexibel strain relief for different cable diameter
Captive dust cover
Scope of delivery:
1 x RJ45 keystone, Cable coder, 1 x captive dust cover, 1 x copper foil, 2 x cable ties, mounting instruction
Specifications:
Extremely small design „Slimline“ for installation with UAE frame sets, design capable
Compact cable presorter for contacting IDC-Terminals AWG 24/1 .. 22/1
Pair management according to TIA 568A /B colour codes
Appropriate for all distribution panels and frames with keystone slots
Flexibel strain relief for different cable diameter
Captive dust cover
Scope of delivery:
1 x RJ45 keystone, Cable coder, 1 x captive dust cover, 1 x copper foil, 2 x cable ties, mounting instruction
Tekniske egenskaber
| 4PPOE certified: | True |
|---|---|
| 360° shield contact: | True |
| AWG-range: | 24 – 22 |
| Category: | 6A (IEC) |
| Complaint to UL94: | V-0 |
| Connection type: | Insulation displacement connector |
| Contact coating: | 50 µ" |
| Contact resistance: | ≤ 20 mΩ |
| Current capacity: | 2 A |
| Dielectric Withstanding Voltage: | 1000 V AC 60Hz |
| Dust cover: | Yes |
| For UAE suitable: | True |
| Housing material: | Zinc die cast |
| Insulation resistance: | ≥ 500 MΩ |
| Mating cycles: | ≥ 750 |
| Max. cable diameter: | 8.5 mm |
| Model: | jack |
| Screened: | True |
| Separate earthing flag: | True |
| Shield contact and strain relief separate: | True |
| Special tool necessary: | False |
| Suitable for flat cable: | False |
| Suitable for litz wire conductor: | True |
| Suitable for round cable: | True |
| Suitable for solid core: | True |
| Temperature range: | -40 – 66 °C |
| Type of connector: | RJ45 8(8) |
