SFP Gigabit Ethernet 1000LX SM 10km, 1310nm
SFP SM 1000LX 10km SFP, 1310nm 1.25G -40..85°C, LC
Varenummer:
FTLF1318P3BTL
EAN Nr.:
4049759140809
Produktinformation til SFP SM 1000LX 10km SFP, 1310nm 1.25G -40..85°C, LC
This SFP transceiver of the brand Finisar is a multirate SFP for Gigabit Ethernet (1,25 Gbit/s) and Fiber Channell (1,06 Gbit/s). Additionally the transceiver features digital diagnostic functions and has an extended temperature range of -40°C up to 85°C.
Up to 1,25 Gbit/s
Hot-pluggable SFP
Integrated digital diagnostic
1310nm Fabry-Perot laser
LC duplex mating face
Up to 10km over 9/125µm singlemode fiber
Low power consumption <600mW tylical
Extended temperature range -40 up to +85°C
RoHS compliant
Up to 1,25 Gbit/s
Hot-pluggable SFP
Integrated digital diagnostic
1310nm Fabry-Perot laser
LC duplex mating face
Up to 10km over 9/125µm singlemode fiber
Low power consumption <600mW tylical
Extended temperature range -40 up to +85°C
RoHS compliant
Tekniske egenskaber
| Certifications: | IEEE 802.3 |
|---|---|
| Compatible to: | Standard |
| Connector: | LC Duplex |
| Construction type: | Mini GBIC |
| Detecting range: | 10 km |
| Digital Diagnostic Monitoring Funktion: | True |
| EMC interference: | small |
| Energy consumption: | 3,3 Volt |
| Fiber qualitiy: | OS2 |
| Gigabit Ethernet: | True |
| Hot-pluggable: | True |
| Medium: | Singlemode |
| Module type: | SFP+ |
| Protocol: | 1000BaseLX |
| RoHS: | True |
| Speed: | 1000 Mbit/s |
| Storage Temperature: | -40 – 85 °C |
| Wave length: | 1310 nm |
Sikkerhedsanvisninger
Warning: Danger of electric shocks and short circuits! Ensure proper earthing to avoid electric shocks. Avoid overloading as this can lead to overheating and short circuits. Check that the housing is undamaged and that there are no exposed contacts or bare wires. Ensure that all electrical connections are made correctly and that the ambient conditions comply with the technical specifications. Always keep a sufficient distance from live devices and avoid misuse.
