Outdoor Cable A-DQ (ZN)B2Y MM OM3 1750N
A-DQ(ZN)B2Y 24G 50/125µ OM3 PE black
Varenummer:
55224.1OM3
EAN Nr.:
4049759072902
Produktinformation til A-DQ(ZN)B2Y 24G 50/125µ OM3 PE black
Application:
For fixed installation outdoor
In cable ducts, tubes and interconnections
Mechanical installation by winch is permitted only when using force meters with recording function
Suitable for underground laying (direct buried)
Characteristics:
Outdoor cable
Resistant to oil, petrol, acid and leach
The cable diameter can vary
For fixed installation outdoor
In cable ducts, tubes and interconnections
Mechanical installation by winch is permitted only when using force meters with recording function
Suitable for underground laying (direct buried)
Characteristics:
Outdoor cable
Resistant to oil, petrol, acid and leach
The cable diameter can vary
Tekniske egenskaber
| Application: | Outside |
|---|---|
| Armouring: | True |
| Cable & Fiber: | IEC 60794-3 |
| Cable & Fiber: | IEC/EN 60794-1 |
| Cable metal free: | True |
| Cabling standards: | ISO/IEC 11801 |
| Cabling standards: | EN 50173-1 |
| Circuit integrity: | False |
| Colour outer sheath: | black |
| Crush resistance: | 1500 N/dm |
| Fiber Colours: | orange |
| Fiber Colours: | turquoise |
| Fiber Colours: | white |
| Fiber Colours: | green |
| Fiber Colours: | grey |
| Fiber Colours: | violet |
| Fiber Colours: | black |
| Fiber Colours: | rose |
| Fiber Colours: | yellow |
| Fiber Colours: | red |
| Fiber Colours: | blue |
| Fiber Colours: | brown |
| Fiber marking: | Colour |
| Fibre category: | OM3 |
| Fibre type: | Multi mode 50/125 |
| Flame retardant: | False |
| Halogen free: | acc. EN 60754-1/2 |
| Halogen free (according to EN 60754-1/2): | True |
| IL max. (dB/km) 850nm: | < 2.7 dB/km |
| IL max. (dB/km) 1300nm: | < 0.8 dB/km |
| Jacket material: | PE |
| Longitudinally watertight: | 3/24 m/h |
| Longitudinal water blocking: | True |
| Low smoke: | False |
| Low smoke (acc. EN 61034-2): | False |
| Oil resistant: | yes |
| Radial water blocking: | True |
| Resistant to chemicals: | True |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -25 – 60 °C |
| Temperature Range (Storage): | -25 – 70 °C |
| Transmission standards: | IEEE 802.3 10Mbit to 100Gbit |
| Tube marking: | Colour |
| Tube Ø: | Up to 24 fibers: 3.5 mm |
| Tube Ø: | Up to 12 fibers: 2.9 |
| Type of tube: | zentrale Bündelader |
| UV resistant: | True |
| With rodent protection: | True |
| With strain relief: | True |
