SC Simplex Adapter without flansch, Plastic housing
Adapter SC Simplex OM1/2 one piece, flangeless, beige, ceramic sleeve
Varenummer:
53510.1
EAN nr.:
4049759103149
Produktinformation für Adapter SC Simplex OM1/2 one piece, flangeless, beige, ceramic sleeve
• Flangeless adapter are good for high density and could be used as keystone modules
in consumption with keystone adapter frames
in consumption with keystone adapter frames
Tekniske egenskaber
| Conform to Standard: | IEC61754-4 |
|---|---|
| Design: | SC-Simplex |
| Dust cover: | True |
| Height: | 9.2 mm |
| Insertion loss 850nm: | - |
| Internal Shutter: | False |
| Length: | 27.5 mm |
| Material housing: | plastic |
| Material sleeve: | ceramic |
| Operating Temperature: | -40 – 85 °C |
| Storage Temperature: | -40 – 85 °C |
| Type of connector connection 1: | SC |
| Type of connector connection 2: | SC |
| Type of fastening: | snap-in |
| Type of housing: | flangeless |
| Width: | 14.7 mm |
Varianter
| Art. Nej. | Betegnelse | Suitable for type of fibre | Model | Insertion loss 1310nm | Insertion loss 850nm | Colour | Category | |
|---|---|---|---|---|---|---|---|---|
| 53513.1OM5 | Adapter SC Simplex OM5 one piece, flangeless, lime green, ceramic sleeve | Multi mode | SC / PC | - | < 0.15 dB | lime green | OM5 | |
| 53512.1 | Adapter SC Simplex OM3 one piece, flangeless, aqua, ceramic sleeve | Multi mode | SC / PC | - | < 0.15 dB | aqua | OM3 | |
| 53510.1 | Adapter SC Simplex OM1/2 one piece, flangeless, beige, ceramic sleeve | Multi mode | SC / PC | < 0.15 dB | - | beige | OM2 | |
| 53511.1 | Adapter SC Simplex SM one piece, flangeless, blue, ceramic sleeve | Single mode | SC / PC | - | < 0.15 dB | blue | OS2 | |
| 53518.1 | Adapter SC/APC Simplex SM one piece, flangeless, green, ceramic sleeve | Single mode | SC / APC | < 0.15 dB | - | green | OS2 |
