Coaxial Cable RG58 C/U, 50 Ohm

Priser kun synlige for indloggede brugere

Coax Cable RG58 C/U, 50 Ohm black, PVC, 1000m
Varenummer: 91058.1
EAN nr.: 4049759073947
Stück

Produktinformation für Coax Cable RG58 C/U, 50 Ohm black, PVC, 1000m

Coaxial cable for high frequent measured data and signals defined characteristic impedance and tight production tolerances in 50 Ohm. Also available as UL type. ( 91058.xUL )

Tekniske egenskaber

Armouring: False
Colour outer sheath: black
Diameter inner conductor: 19/0.19 mm
Diameter outer conductor: 0.12 mm
Dielectric: Fully-PE
Halogen free (acc. EN 50267-2-2): False
Inner conductor category: Class 5 = flexible
Inner conductor material: CU, tinned
Jacket material: PVC
Operating temperature, fix: -20 – 75 °C
Operating temperature, flexible: -20 – 75 °C
Outer conductor material: CU, tinned
Type of outer conductor: braiding

Varianter

Art. Nej. Betegnelse Impedance Lenght Outer diameter approx.
91058.1 Coax Cable RG58 C/U, 50 Ohm black, PVC, 1000m 50 Ohm 1.0 m 5.1 mm Vælg varianter
91058.100 Coax Cable RG58 C/U, 50 Ohm black, PVC, 100m ring 50 Ohm 100.0 m 5.1 mm Vælg varianter
