DVI 24+1 Dual Link Connection Cable
DVI-D Dual Link Cable, 2x DVI-D 24+1, M-M, AWG 30, 2,0m, black
Varenummer:
K5434.2
EAN Nr.:
4049759208882
Produktinformation til DVI-D Dual Link Cable, 2x DVI-D 24+1, M-M, AWG 30, 2,0m, black
3x Shielding: foil + braiding + PIMF
Conductor: bare copper, Jacket: PVC
Plugs and contacts gold plated and moulded
Both sides assembled with ferrite core to dejam signals in the cable (better EMV characteristics)
Cable length up to 20m!
Dual Link cable
Support resolutions up to 2560 x 1600
Conductor: bare copper, Jacket: PVC
Plugs and contacts gold plated and moulded
Both sides assembled with ferrite core to dejam signals in the cable (better EMV characteristics)
Cable length up to 20m!
Dual Link cable
Support resolutions up to 2560 x 1600
Tekniske egenskaber
| Connection type connection 1: | Plug |
|---|---|
| Connection type connection 2: | Plug |
| Diameter: | - |
| Number of poles connection 1: | 25 |
| Number of poles connection 2: | 25 |
| Type of connector connection 1: | DVI-D 24+1 |
| Type of connector connection 2: | DVI-D 24+1 |
Varianten
| Art. Nr. | Bezeichnung | Colour | Length | Diameter | AWG | |
|---|---|---|---|---|---|---|
| K5434.2 | DVI-D Dual Link Cable, 2x DVI-D 24+1, M-M, AWG 30, 2,0m, black | black | 2.0 m | - | 30 | |
| K5434.3 | DVI-D Dual Link Cable, 2x DVI-D 24+1, M-M, AWG 30, 3,0m, black | Black | 3.0 m | 7.3 mm | 30AWG | |
| K5434.5V2 | DVI-D Dual Link Cable, 2x DVI-D 24+1, M-M, AWG 28, 5,0m, black | Black | 5.0 m | 7.3 mm | 28AWG |
