MTP®-F/MTP®-F 36-fiber matrix Patch cable OS2, Code A
MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 5m
Varenummer:
MTPF36MTPFOS2-5-A
EAN Nr.:
4049759237325
Produktinformation til MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 5m
Application: Server to Server- / Switch to Switch connection,
Suitable for transmission links up to 100 Gigabit
Connector manufacturer: US Conec
Matrix: 12 Fibers
Singlemode variant always as APC version
Colour: OM5 lime green, OM4 erica-violet, OM3 aqua and OS2 yellow
Available lengths: 1m up to 100m
Note: In each MTP® transmission link, a type B (crossed) patch cable is required
MTP Singlemode connectors are in APC version
Suitable for transmission links up to 100 Gigabit
Connector manufacturer: US Conec
Matrix: 12 Fibers
Singlemode variant always as APC version
Colour: OM5 lime green, OM4 erica-violet, OM3 aqua and OS2 yellow
Available lengths: 1m up to 100m
Note: In each MTP® transmission link, a type B (crossed) patch cable is required
MTP Singlemode connectors are in APC version
Tekniske egenskaber
Cable Diameter: | 9.0 mm |
---|---|
Category: | OS2 |
Coding: | Type A straight |
Colour outer sheath: | yellow |
Connector connection 1: | MTP-F |
Connector connection 2: | MTP-F |
Fibre type: | G657A1 9/125 |
Halogen free (according to EN 50267-2-3): | True |
Jacket material: | LSZH |
Operating Temperature: | 0 – 50 °C |
Storage Temperature: | -20 – 70 °C |
With rodent protection: | False |
Varianten
Art. Nr. | Bezeichnung | Number of connectors connection 1 | Number of fibres | Number of connectors connection 2 | Length | |
---|---|---|---|---|---|---|
MTPF36MTPFOS2-5-A | MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 5m | 3 x MTP® female | 36 | 3 x MTP® female | 5.0 m | |
MTPF36MTPFOS2-10-A | MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 10m | 3 x MTP® female | 36 | 3 x MTP® female | 10.0 m | |
MTPF36MTPFOS2-15-A | MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 15m | 3 x MTP® female | 36 | 3 x MTP® female | 15.0 m | |
MTPF36MTPFOS2-20-A | MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 20m | 3 x MTP® female | 36 | 3 x MTP® female | 20.0 m | |
MTPF36MTPFOS2-25-A | MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 25m | 3 x MTP® female | 36 | 3 x MTP® female | 25.0 m | |
MTPF36MTPFOS2-30-A | MTP®/APC(F)-MTP®/APC(F) Patch cable OS2 36 fibers Typ A LSZH yellow 30m | 3 x MTP® female | 36 | 3 x MTP® female | 30.0 m |
