RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, black
Priser kun synlige for indloggede brugere
RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 0,15m, black
Varenummer:
K8109SW.0,15
EAN nr.:
4049759247386
Produktinformation für RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 0,15m, black
The unshielded Cat.6A RJ45 premium patch cable ensures very good characteristics for 10 Gigabit Ethernet applications. The moulded grommet captivates with its slim design and thus simplifies the insertion process in cramped conditions.
Cross section 4 x 2 x AWG24/7
Cast anti-kink grommet with length imprint, slim design
Cross section 4 x 2 x AWG24/7
Cast anti-kink grommet with length imprint, slim design
Tekniske egenskaber
| (Halogenfree): | True |
|---|---|
| AWG-size: | 24/7 |
| Allocation: | acc. TIA/EIA 568B |
| Anti-kink sleeve: | plugged in |
| Area of Application: | Data center, Structured cabling |
| Bandwidth: | 500MHz |
| Bending radius: | 30 mm |
| Cable construction: | 4x2 |
| Cable type: | U/UTP |
| Cabling Standard: | EN50173, ISO/IEC 11801 |
| Category: | 6A (TIA) |
| Colour anti-kink sleeve: | black |
| Colour outer sheath: | black |
| Conductor Material: | Copper |
| Connector: | IEC 60603-7-41 |
| Connector type: | RJ45 Standard blue |
| Contacts: | 50 µ" gold plated |
| Current capacity: | max. 1 A |
| Fire retardant version: | True |
| Flame-retardant: | acc. IEC60332-1 |
| Halogen-free: | True |
| Jacket material: | LSZH |
| Locking lever: | True |
| Low smoke: | True |
| Mating cycles: | 2000 |
| Model: | Unshielded |
| NVP value: | - % |
| Oil resistant (acc. EN 60811-2-1): | False |
| Oil resistant (according to EN 60811-404): | False |
| Operating-/ tempering voltage: | max. 50 V DC |
| Outer diameter of the cable: | 6.0 mm |
| POE class: | 4PPoE acc. to IEEE802.3bt, PoE+ acc. to IEEE802.3at, PoE acc. to IEEE802.3af |
| Pin assignment: | 1:1 |
| Printing: | Cat.6A PREMIUM Patchcord U/UTP 4x2xAWG24/7 ISO/IEC11801 TIA/EIA-568-C.2 ***10Gigabit Ethernet*** |
| Suitable for degree of protection (IP): | IP20 |
| Temperature range: | 0 – 60 °C |
| Transmission: | 10Gbit |
| Type of connector connection 1: | RJ45 8(8) |
| Type of connector connection 2: | RJ45 8(8) |
Varianter
| Art. Nej. | Betegnelse | Length | Length tolerance | |
|---|---|---|---|---|
| K8109SW.0,15 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 0,15m, black | 0.15 m | ±5 % | Vælg varianter |
| K8109SW.0,25 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 0,25m, black | 0.25 m | ±5 % | Vælg varianter |
| K8109SW.0,5 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 0,5m, black | 0.5 m | ±5 % | Vælg varianter |
| K8109SW.1 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 1m, black | 1.0 m | ±5 % | Vælg varianter |
| K8109SW.1,5 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 1,5m, black | 1.5 m | ±5 % | Vælg varianter |
| K8109SW.2 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 2m, black | 2.0 m | ±5 % | Vælg varianter |
| K8109SW.3 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 3m, black | 3.0 m | ±5 % | Vælg varianter |
| K8109SW.5 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 5m, black | 5.0 m | ±5 % | Vælg varianter |
| K8109SW.7,5 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 7,5m, black | 7.5 m | ±5 % | Vælg varianter |
| K8109SW.10 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 10m, black | 10.0 m | ±5 % | Vælg varianter |
| K8109SW.15 | RJ45 Patch cable U/UTP, Cat.6A, LSZH, Premium, 500MHz, 15m, black | 15.0 m | ±5 % | Vælg varianter |
