Splice box gy sliding LC OM4 12x fanout pigtails and 6x duplex adapter
Indhold:
1 Stück
Splice box gy sliding LC OM4 12x fanout pigtails and 6x duplex adapter
Varenummer:
BA71901L12OM4
EAN nr.:
4049759284503
Produktinformation til Splice box gy sliding LC OM4 12x fanout pigtails and 6x duplex adapter
Extendable 1U 19" Form Factor – Allows for compact rack mounting and facilitates maintenance and access to the splice level.
Front panel with 6 LC duplex couplings and 6 blanking plugs – Ensures a clean pre-assembled assembly and keeps unused positions neatly sealed.
12 prepared LC pigtails with LSZH jacket and 2m length – Support efficient splicing organisation and reduce installation effort.
The splice box is designed for Multimode 50/125 in OM4 and combines pre-assembled LC duplex connections with a service-friendly, extendable design. The sheet steel housing in grey according to RAL 7035 and the vertical alignment of the couplings support the clean guidance of the fibre optic lines. The ceramic ferrule guide as well as pre-assembled crimp/ANT splice holders and enclosed shrink splice holders complement the concept for professional use in the 19-inch rack.
Technical details
• Extendable: extendable
• Fibre class: OM4
• Fibre type: Multimode 50/125
• Couplings: LC-Duplex
• With number of couplings/adapters: 6
• Coupling material: plastic
• Couplings (ferrule guide): Ceramic
• Alignment of the couplings/adapters: vertical
• Pigtail: 12 x LC
• Pigtail prepared: discontinued
• Pigtail Coating Material: LSZH
• Pigtail length: 2 m
• Pigtail Buffer Type: Loose-Buffered
• Pigtail diameter: 0.9 mm
• Pigtail Colour: DIN
• Pigtail connector colour: heather violet
• Number of height units (U): 1U
• Colour: grey
• Material: sheet steel
• RAL number: 7035
• Connector type Outside: LC Duplex
• Connector type Inside: LC Duplex
• Splice Trays (Quantity): 1
• Splice trays (capacity): 4
• Splice holder (splice holder type): Crimp/ANT splice holder (pre-assembled) and shrink splice holder (included)
• With front panel: Yes
• With housing: Yes
• With pigtails: Yes
Front panel with 6 LC duplex couplings and 6 blanking plugs – Ensures a clean pre-assembled assembly and keeps unused positions neatly sealed.
12 prepared LC pigtails with LSZH jacket and 2m length – Support efficient splicing organisation and reduce installation effort.
The splice box is designed for Multimode 50/125 in OM4 and combines pre-assembled LC duplex connections with a service-friendly, extendable design. The sheet steel housing in grey according to RAL 7035 and the vertical alignment of the couplings support the clean guidance of the fibre optic lines. The ceramic ferrule guide as well as pre-assembled crimp/ANT splice holders and enclosed shrink splice holders complement the concept for professional use in the 19-inch rack.
Technical details
• Extendable: extendable
• Fibre class: OM4
• Fibre type: Multimode 50/125
• Couplings: LC-Duplex
• With number of couplings/adapters: 6
• Coupling material: plastic
• Couplings (ferrule guide): Ceramic
• Alignment of the couplings/adapters: vertical
• Pigtail: 12 x LC
• Pigtail prepared: discontinued
• Pigtail Coating Material: LSZH
• Pigtail length: 2 m
• Pigtail Buffer Type: Loose-Buffered
• Pigtail diameter: 0.9 mm
• Pigtail Colour: DIN
• Pigtail connector colour: heather violet
• Number of height units (U): 1U
• Colour: grey
• Material: sheet steel
• RAL number: 7035
• Connector type Outside: LC Duplex
• Connector type Inside: LC Duplex
• Splice Trays (Quantity): 1
• Splice trays (capacity): 4
• Splice holder (splice holder type): Crimp/ANT splice holder (pre-assembled) and shrink splice holder (included)
• With front panel: Yes
• With housing: Yes
• With pigtails: Yes
| Adapter material: | plastic |
|---|---|
| Adapters: | LC-Duplex |
| Couplings (ferrule guide): | Ceramic |
| Depth: | 243 mm |
| Depth adjustment: | 40 mm |
| Fibre class: | OM4 |
| Fibre type: | Multi mode 50/125 |
| Height: | 44 mm |
| Material: | Steel sheet |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Packaging: | EFB-Elektronik Carton |
| Pigtails prepared: | stripped |
| Remark: | vertical |
| Sliding: | sliding |
| Splice cassettes (capacity): | 4 |
| Splice cassettes (number): | 1 |
| Splice cassettes (number of splice holders): | 18 x crimp splice protection holder per splice cassette2 x shrink splice protection holder per splice cassette |
| Splice cassettes (splice holder capacity): | 2 per splice cassette |
| Splice holder (splice capacity):: | 1x Crimp/ANT = 12 splices1x Heatshrink = 6 splices |
| Splice holder (splice protection type): | Crimp/ANT (pre-assembled)Heatshrink (included) |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -40 – 80 °C |
| Width: | 482 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | True |
Tekniske egenskaber
| Adapter material: | plastic |
|---|---|
| Adapters: | LC-Duplex |
| Couplings (ferrule guide): | Ceramic |
| Depth: | 243 mm |
| Depth adjustment: | 40 mm |
| Fibre class: | OM4 |
| Fibre type: | Multi mode 50/125 |
| Height: | 44 mm |
| Material: | Steel sheet |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of height units: | 1 U |
| Packaging: | EFB-Elektronik Carton |
| Pigtails prepared: | stripped |
| Remark: | vertical |
| Sliding: | sliding |
| Splice cassettes (capacity): | 4 |
| Splice cassettes (number): | 1 |
| Splice cassettes (number of splice holders): | 18 x crimp splice protection holder per splice cassette2 x shrink splice protection holder per splice cassette |
| Splice cassettes (splice holder capacity): | 2 per splice cassette |
| Splice holder (splice capacity):: | 1x Crimp/ANT = 12 splices1x Heatshrink = 6 splices |
| Splice holder (splice protection type): | Crimp/ANT (pre-assembled)Heatshrink (included) |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -40 – 80 °C |
| Width: | 482 mm |
| With front plate: | True |
| With housing: | True |
| With pigtails: | True |
Varianter
| Art. Nej. | Betegnelse | Type of connector external | Colour | Suitable for number of couplings/adapters | Pigtail | With number of couplings/adapters | RAL-number | Type of connector interior | Pigtail Coating material | Minimal bendung radius static | Pigtail colour | Pigtail Buffertype | Return loss 850nm | Adapter colour | Insertion loss 850nm | Pigtail diameter | Minimal bendung radius dynamic | Scope of delivery | Pigtail length | Pigtail plug colour | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BA71901L12OM4 | Splice box gy sliding LC OM4 12x fanout pigtails and 6x duplex adapter | LC-Duplex | grey | 12 | 12 x LC | 6 | 7035 | LC-Duplex | LSZH | 10xD | DIN | Loose-Buffered | ≥35 dB | erica violet | ≤0.25 dB | 0.9 mm | 20xD | 19'' splice box extendable with frontpanel and<br>6xadapter, 6xadapter dummy, <br>12xpigtail+Test protocol, 1xsplice cassette+cover+screw, 1xcrimp splice protector holder, 2xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | 2 m | erica violet | |
| BA71901L24OM4 | Splice box gy sliding LC OM4 24x fanout pigtails and 12x duplex adapter | LC-Duplex | grey | 12 | 24 x LC | 12 | 7035 | LC-Duplex | LSZH | 10xD | DIN | Loose-Buffered | ≥35 dB | erica violet | ≤0.25 dB | 0.9 mm | 20xD | 19'' splice box extendable with frontpanel and<br>12xadapter, 24xpigtail+Test protocol, 2xsplice cassette+cover+screw, 2xcrimp splice protector holder, 4xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | 2 m | erica violet | |
| BA71901L48OM4 | Splice box gy sliding LC OM4 48x fanout pigtails and 24x duplex adapter | LC-Duplex | grey | 24 | 48 x LC | 24 | 7035 | LC-Duplex | LSZH | 10xD | DIN | Loose-Buffered | ≥35 dB | erica violet | ≤0.25 dB | 0.9 mm | 20xD | 19'' splice box extendable with frontpanel and<br>24xadapter, 48xpigtail+Test protocol, 4xsplice cassette+cover+screw, 4xcrimp splice protector holder, 8xheat shrink splice protection holder<br>6xself adhesive fiber tray, 1xM20 | 2 m | erica violet |
