Trunk cable U-DQ(ZN)BH OS2 12E (1x12) LC-LC
EFB-Elektronik
Trunk cable U-DQ(ZN)BH OS2 12E (1x12) LC-LC,140m Dca LSZH
Varenummer:
O8342S140OS2
EAN nr.:
4049759306427
Produktinformation til Trunk cable U-DQ(ZN)BH OS2 12E (1x12) LC-LC,140m Dca LSZH
EFB sets standards in high quality
For many years, EFB has been offering individual fiber optic assemblies from its own production for insertion into cable ducts and shafts. Now there is also a standard line, which is kept in stock. These are pre-assembled trunk cables with LC connectors in the OS2, OM3 and OM4 categories. The stocked lengths can be found in the overview below.
Advantages:
Fast delivery: standard lengths up to 200 m in standard quantities available from stock
Reduction of installation costs: No splicing and assembly equipment required
Reduced installation time: cable ready for direct installation
Traceable quality: cable with serial number and measurement protocol
Performance features:
4, 8 or 12 fibers per cable
Fibre class OS2, OM3 or OM4
Factory production, polishing and function test
Double-sided assembled stepped cable whips (longest length 1 m)
Identification of the remote individual cables with cable markers (numbers)
Serial number on the cable
Attenuation protocol for each individual fiber is provided
Delivery on both sides with fabric hose as drawing-in tube
Delivery up to 40 m in polybag, from 50 m on disposable drum
Raw cable: CPR-Class Dca
Length of the draw-in tube of 130cm, diameter: 4 fiber approx. 10mm, 8 fiber approx. 15mm, 12 fiber approx. 20mm
For many years, EFB has been offering individual fiber optic assemblies from its own production for insertion into cable ducts and shafts. Now there is also a standard line, which is kept in stock. These are pre-assembled trunk cables with LC connectors in the OS2, OM3 and OM4 categories. The stocked lengths can be found in the overview below.
Advantages:
Fast delivery: standard lengths up to 200 m in standard quantities available from stock
Reduction of installation costs: No splicing and assembly equipment required
Reduced installation time: cable ready for direct installation
Traceable quality: cable with serial number and measurement protocol
Performance features:
4, 8 or 12 fibers per cable
Fibre class OS2, OM3 or OM4
Factory production, polishing and function test
Double-sided assembled stepped cable whips (longest length 1 m)
Identification of the remote individual cables with cable markers (numbers)
Serial number on the cable
Attenuation protocol for each individual fiber is provided
Delivery on both sides with fabric hose as drawing-in tube
Delivery up to 40 m in polybag, from 50 m on disposable drum
Raw cable: CPR-Class Dca
Length of the draw-in tube of 130cm, diameter: 4 fiber approx. 10mm, 8 fiber approx. 15mm, 12 fiber approx. 20mm
| Anti-kink sleeve: | put-on |
|---|---|
| Bend optimized fiber: | no |
| CPR class: | Dca |
| Cable structure: | Mehrfaser |
| Cable type: | U-DQ (ZN) BH |
| Cable Ø: | 5.8 mm |
| Category: | OS2 G652D |
| Colour outer sheath: | black |
| Dimension Cable divider: | 11.5 x 372 mm |
| Fibre type: | Single mode 9/125 |
| Flame retardant: | Ja |
| Insertion loss 1310nm: | < 1.5 dB |
| Jacket material: | LSZH |
| Max. Tension (long term): | 300 N |
| Min. Bending radius (Dynamic): | >20xOD mm |
| Min. Bending radius (Static): | >10xOD mm |
| Number of fibers: | 12 |
| Operating Temperature: | -40 – 70 °C |
| Packaging: | Polybag |
| Scope of delivery: | Cable, measurement protocol, GPSR instruction leaflet, insertion aid |
| Storage Temperature: | -40 – 70 °C |
| Type of connector connection 1: | LC |
| Type of connector connection 2: | LC |
