Breakout Indoor Cable I-V (ZN) HH 50/125µ OM4
Leoni Fiber Optics
I-V(ZN)HH Breakout OM4 2G (2x1) Eca 600N LSZH erica violet 2.8mm
Varenummer:
55002.1OM4
EAN nr.:
4049759072629
Produktinformation til I-V(ZN)HH Breakout OM4 2G (2x1) Eca 600N LSZH erica violet 2.8mm
Indoor application
Installation in shafts, underfloor area
Secondary cabling (vertical): riser area (backbone)
Tertiary cabling (horizontal): working area, fiber-to-the-desk FTTD
Trunk cable, patch- and adapter cable
Indoor cable
Non-metallic, halogenfree, gel free
Suitable for connector assembly
Operation: -20°C ~ 60°C
Installation: -5°C ~ 50°C
Installation in shafts, underfloor area
Secondary cabling (vertical): riser area (backbone)
Tertiary cabling (horizontal): working area, fiber-to-the-desk FTTD
Trunk cable, patch- and adapter cable
Indoor cable
Non-metallic, halogenfree, gel free
Suitable for connector assembly
Operation: -20°C ~ 60°C
Installation: -5°C ~ 50°C
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable metal free: | True |
| Cable silicone free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | aqua |
| Crush resistance: | 300 N/dm |
| Fiber Colours: | black, blue, brown, green, grey, orange, red, rose, turquoise, violet, white, yellow |
| Fiber marking: | Colour |
| Fibre category: | OM4 |
| Fibre type: | Multimode 50/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Halogen free: | acc. to EN 60754-1/2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 850nm: | 2.7 dB/km |
| IL max. (dB/km) 1300nm: | 0.8 dB/km |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Low smoke: | True |
| Low smoke (acc. EN 61034-2): | True |
| Oil resistant: | no |
| Oil resistant (acc. EN 60811-2-1): | False |
| Radial water blocking: | False |
| Resistant to chemicals: | False |
| Scope of delivery: | 1x Cable1x Drum |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -25 – 70 °C |
| Type of tube: | Tight |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
Tekniske egenskaber
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable metal free: | True |
| Cable silicone free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | aqua |
| Crush resistance: | 300 N/dm |
| Fiber Colours: | black, blue, brown, green, grey, orange, red, rose, turquoise, violet, white, yellow |
| Fiber marking: | Colour |
| Fibre category: | OM4 |
| Fibre type: | Multimode 50/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Halogen free: | acc. to EN 60754-1/2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 850nm: | 2.7 dB/km |
| IL max. (dB/km) 1300nm: | 0.8 dB/km |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Low smoke: | True |
| Low smoke (acc. EN 61034-2): | True |
| Oil resistant: | no |
| Oil resistant (acc. EN 60811-2-1): | False |
| Radial water blocking: | False |
| Resistant to chemicals: | False |
| Scope of delivery: | 1x Cable1x Drum |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -25 – 70 °C |
| Type of tube: | Tight |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
Varianter
| Art. Nej. | Betegnelse | Category | CPR-Class | Number of fibers | Tensile force max. | Cable Ø | Construct | Outer diameter approx. | Bending radius | VDE-Name | Weight | Number of fibres per tube | Suitable for underground installation | Fire load | Minimum bending radius (dynamic) | Minimum bending radius (static) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 55002.1OM4 | I-V(ZN)HH Breakout OM4 2G (2x1) Eca 600N LSZH erica violet 2.8mm | OM4 | Eca | 2 | 600 N | 3.9 x 6.8 mm | 02G ( 2 x 2.8 ) Multimode OM4 | 3.9x6.8 mm | 60 mm | I-V(ZN)HH 2G 50/125 | 28 kg/km | - | - | - | - | - | |
| 55004.1OM4 | I-V(ZN)HH Breakout OM4 4G (4x1) 800N LSZH turquoise 2.8mm | OM4 | Eca | 4 | 800 N | 8.3 mm | 04G ( 4 x 2.8 ) Multimode OM4 | 8.5 mm | 150 mm | I-V(ZN)HH 4G 50/125 | 62 kg/km | - | - | - | - | - | |
| 55008.1OM4 | Breakout Indoor Cable I-V (ZN) HH 50/125µ OM4 | OM4 | Eca | 8 | 1000 N | 9.4 mm | (8x1) | 12.1 mm | - | I-V(ZN)HH 8G 50/125 | 85 kg/km | 1 | False | 1.28 MJ/m | 15xOD mm | 10xOD mm |
Produktinformation til I-V(ZN)HH Breakout OM4 2G (2x1) Eca 600N LSZH erica violet 2.8mm
Indoor application
Installation in shafts, underfloor area
Secondary cabling (vertical): riser area (backbone)
Tertiary cabling (horizontal): working area, fiber-to-the-desk FTTD
Trunk cable, patch- and adapter cable
Indoor cable
Non-metallic, halogenfree, gel free
Suitable for connector assembly
Operation: -20°C ~ 60°C
Installation: -5°C ~ 50°C
Installation in shafts, underfloor area
Secondary cabling (vertical): riser area (backbone)
Tertiary cabling (horizontal): working area, fiber-to-the-desk FTTD
Trunk cable, patch- and adapter cable
Indoor cable
Non-metallic, halogenfree, gel free
Suitable for connector assembly
Operation: -20°C ~ 60°C
Installation: -5°C ~ 50°C
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable metal free: | True |
| Cable silicone free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | aqua |
| Crush resistance: | 300 N/dm |
| Fiber Colours: | black, blue, brown, green, grey, orange, red, rose, turquoise, violet, white, yellow |
| Fiber marking: | Colour |
| Fibre category: | OM4 |
| Fibre type: | Multimode 50/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Halogen free: | acc. to EN 60754-1/2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 850nm: | 2.7 dB/km |
| IL max. (dB/km) 1300nm: | 0.8 dB/km |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Low smoke: | True |
| Low smoke (acc. EN 61034-2): | True |
| Oil resistant: | no |
| Oil resistant (acc. EN 60811-2-1): | False |
| Radial water blocking: | False |
| Resistant to chemicals: | False |
| Scope of delivery: | 1x Cable1x Drum |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -25 – 70 °C |
| Type of tube: | Tight |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
| Application: | Inside |
|---|---|
| Armouring: | False |
| Blow in: | False |
| Cable metal free: | True |
| Cable silicone free: | True |
| Circuit integrity: | No |
| Colour outer sheath: | aqua |
| Crush resistance: | 300 N/dm |
| Fiber Colours: | black, blue, brown, green, grey, orange, red, rose, turquoise, violet, white, yellow |
| Fiber marking: | Colour |
| Fibre category: | OM4 |
| Fibre type: | Multimode 50/125 |
| Flame retardant: | acc. to EN 60332-1-2 |
| Halogen free: | acc. to EN 60754-1/2 |
| Harmonised Standard: | EN 50575 |
| IL max. (dB/km) 850nm: | 2.7 dB/km |
| IL max. (dB/km) 1300nm: | 0.8 dB/km |
| Jacket material: | LSZH |
| Longitudinal water blocking: | False |
| Low smoke: | True |
| Low smoke (acc. EN 61034-2): | True |
| Oil resistant: | no |
| Oil resistant (acc. EN 60811-2-1): | False |
| Radial water blocking: | False |
| Resistant to chemicals: | False |
| Scope of delivery: | 1x Cable1x Drum |
| Temperature Range (Installation): | -5 – 50 °C |
| Temperature Range (Operation): | -40 – 80 °C |
| Temperature Range (Storage): | -25 – 70 °C |
| Type of tube: | Tight |
| UV resistant: | no |
| With rodent protection: | False |
| With strain relief: | True |
Varianter
| Art. Nej. | Betegnelse | Category | CPR-Class | Number of fibers | Tensile force max. | Cable Ø | Construct | Outer diameter approx. | Bending radius | VDE-Name | Weight | Number of fibres per tube | Suitable for underground installation | Fire load | Minimum bending radius (dynamic) | Minimum bending radius (static) | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 55002.1OM4 | I-V(ZN)HH Breakout OM4 2G (2x1) Eca 600N LSZH erica violet 2.8mm | OM4 | Eca | 2 | 600 N | 3.9 x 6.8 mm | 02G ( 2 x 2.8 ) Multimode OM4 | 3.9x6.8 mm | 60 mm | I-V(ZN)HH 2G 50/125 | 28 kg/km | - | - | - | - | - | |
| 55004.1OM4 | I-V(ZN)HH Breakout OM4 4G (4x1) 800N LSZH turquoise 2.8mm | OM4 | Eca | 4 | 800 N | 8.3 mm | 04G ( 4 x 2.8 ) Multimode OM4 | 8.5 mm | 150 mm | I-V(ZN)HH 4G 50/125 | 62 kg/km | - | - | - | - | - | |
| 55008.1OM4 | Breakout Indoor Cable I-V (ZN) HH 50/125µ OM4 | OM4 | Eca | 8 | 1000 N | 9.4 mm | (8x1) | 12.1 mm | - | I-V(ZN)HH 8G 50/125 | 85 kg/km | 1 | False | 1.28 MJ/m | 15xOD mm | 10xOD mm |
Producentangivelse
WEINERT Fiber Optics GmbH
Mittlere-Motsch-Str. 26
96515 Sonneberg
sales-europe@weinert-industries.com
https://www.weinert-industries.com
