FOS-3110, 10-Port L2 Managed Gigabit Ethernet Fiber Switch, 8x 100/1000 SFP, 2x Combo RJ45/SFP
10-Port L2 Managed Gigabit Ethernet Fiber Switch, 8x GE SFP, 2x Combo RJ45/SFP
Varenummer:
FOS-3110
EAN Nr.:
4049759193881
Produktinformation til 10-Port L2 Managed Gigabit Ethernet Fiber Switch, 8x GE SFP, 2x Combo RJ45/SFP
8x 100/1000Mbps SFP Slots
2x 100/1000Mbps RJ45/SFP
SFP Slots support for MiniGBICs 100-FX, 1000Base-X
Management: SNMP, WEB, RMON, Telnet and TFTP management
IPv6, IGMPv3, Multicast, VLAN, QOS, Autonegotiation, Auto MDI/MDIX and more.
1x RS232 RJ45 Port, 1 x Digital input (Terminal block), Diagnostic led
19" and 10" Bracket included
Metal housing Fanless (L x B x H): 210 x 235 x 44 mm
2x 100/1000Mbps RJ45/SFP
SFP Slots support for MiniGBICs 100-FX, 1000Base-X
Management: SNMP, WEB, RMON, Telnet and TFTP management
IPv6, IGMPv3, Multicast, VLAN, QOS, Autonegotiation, Auto MDI/MDIX and more.
1x RS232 RJ45 Port, 1 x Digital input (Terminal block), Diagnostic led
19" and 10" Bracket included
Metal housing Fanless (L x B x H): 210 x 235 x 44 mm
Tekniske egenskaber
| Depth: | 235.00 mm |
|---|---|
| Ethernet: | True |
| Fast Ethernet: | True |
| Gigabit Ethernet: | True |
| Height: | 44.0 mm |
| Layer 2: | True |
| Manageable: | True |
| Management: | L2 |
| Manufacturer: | CTS |
| Mounting method: | 482.6 mm (19 inch) mounting |
| Number of combination-ports RJ45/Mini GBIC: | 2 |
| Number of ports 1000 Mbps Mini GBIC: | 8 |
| Width: | 210.0 mm |
Sikkerhedsanvisninger
Warning: Danger of electric shocks and short circuits! Ensure proper earthing to avoid electric shocks. Avoid overloading as this can lead to overheating and short circuits. Check that the housing is undamaged and that there are no exposed contacts or bare wires. Ensure that all electrical connections are made correctly and that the ambient conditions comply with the technical specifications. Always keep a sufficient distance from live devices and avoid misuse.
Producentangivelse
Connection Technology Systems Northern Europe AB
August Barks gata 21b, Västra Frölunda
42132 Västra Frölunda
order@ctsystem.se
https://www.ctsystem.com
